MODIFIED SINE WAVE INVERTER
Model 812 MS

12 VDC to 120 VAC
Modified Sine Wave Inverter

800 Watt Power Output

Model 812 MS is a high efficiency modified sine wave inverter which converts 12 Volts DC (Nominal) to 800 watts of AC power at 120 Volts, 60 Hz. The unit comes with a set of battery cable lugs. Features include protection against overload, over-temperature, low input and high input voltage. The front-end LED display indicates battery voltage and output power levels. Modified sine wave power is suitable for operating lamps, motors, and most resistive loads.

General Application

  • For mounting in weather protected compartments only

Specifications

  • Input Volts: 11-15 VDC
  • Output Watts: 800
  • Output Volts: 120 VAC; 60 +, – 0.5 Hz.
  • Input Amps: 80 max.
  • Efficiency: 85% minimum
  • Output regulation: 3%, No Load to Full Load
  • Output Waveform: Modified Sine Wave
  • Dimensions (L x W x H): 17” x 8.5” x 3.5”
  • Weight: 8 lbs

features

  • High efficiency
  • High output current surge capability
  • Low battery alarm / shut down
  • Low idle power draw: < 0.05 Amps
  • Compact and light weight
  • Two output receptacles
  • Cool Operation
  • Easy Installation
  • Electronically protected against output overloads

Applications

  • Service Vehicles
  • Boats & Recreation Vehicles
  • Telecommunication
  • Construction Sites
  • Solar Power Systems
  • Emergency backup power
  • Home electronics: TV, VCR, Video Games, Computers, Printers, Monitors, Fax Machines, Tools and Appliances Computers
  • Microwave Ovens
  • Video Equipment
  • Industrial Controls
  • Communications Equipment
